INLINE GUN

Graco 244161 Contractor Gun In-Line Valve

Genuine Graco Contractor In-Line Valve Gun. Refer to the parts manual for your sprayer to ensure part compatibility

Application: Graco's dedication to delivering the highest quality products also allows you to protect your investment by offering products that can be repaired to ensure years of reliable service. High quality parts have years of service, but wear parts will need replacement over time. Use Genuine Graco parts to keep your sprayer in peak working order for years to come.

• Can be used with other extended reach tools such as Heavy Duty Extensions and Telescoping Extensions for Pressure Rolling
• Provides a straight connection to extensions for the most optimal rolling position
• In-handle paint filter and built-in swivel connection for top spraying performance

• Model: Graco

• For Use With: Pole Gun

• Inlet Size (cm): 0.635
• Inlet Size (in): 1/4
• Inlet Size (mm): 6.35

• Inlet Thread Type: NPSM

• Maximum Working Pressure (bar): 248
• Maximum Working Pressure (kPa): 24800
• Maximum Working Pressure (MPa): 25
• Maximum Working Pressure (psi): 3600

• Outlet Size (cm): 2.2225
• Outlet Size (in): 7/8
• Outlet Size (mm): 22.225
• Outlet Thread Type: UNF
