    Qx No Radio, No Display, 20V Pistol 18 Nm Standard Quick Connect 1/4 Inch

    IR QXFN2PT018PQ04

    1/4" Hex 20V Cordless QX Precision Fastening Screwdriver, 159 in-lb Torque, 500 RPM, Pistol

    Description: Designed to replace traditional clutch tools, the 20V pistol grip QXFN Precision Screwdriver offers the precision and quality of the QX Connect Series in an affordable, simple to set up tool. Reducing torque reaction doesn't have to be complicated with the QX Connect Series Ergonomic Tightening System. Add mobility and enhance the simplicity and flexibility of Ingersoll Rand QX Connect Series cordless assembly tools with the INSIGHT Connect app.

    Features And Benefits:

    • Comes with 32 programmable tightening configuration.
    • 1,200 cycles of onboard tightening data storage
    • Configurable preventative maintenance alarms.
    • Intuitive qualitative feedback using Green, Red, and Yellow indicators.
    • All QX Series IQV 20 tools are compatible with both the BL2022 and BL2012 batteries. The BL2022 is optimum for longer use applications while the BL2012 is ideal for tighter spaces and reduced weight. The 20 volt batteries utilize our 20V battery charger.
    • Insight Connect Android APP Link.
    • Programming Methods: Through USB with Insight Connect App available on Android, Through ICS Software, Through INISGHTqcx Controllers.
    • Includes: Bare tool only, batteries and charger sold separately.
    • Actuation/Throttle Type/Switch Type: Trigger
    • Anvil Length: Standard
    • Built-in Light: Yes
    • Color: Grey
    • Configuration/Handle Type: Pistol Grip
    • Data Storage Capacity: 1200 cycles
    • Drive Size (in): 1/4
    • Drive Type: Hex
    • Max Free Speed (rpm): 500
    • Max Torque (ft-lb): 13
    • Max Torque (in-lb): 159
    • Max Torque (nm): 18
    • Motor: Brushless Motor
    • Power Source: Battery Powered
    • Product Length (in): 8.48
    • Product Height (in) (with Battery): 10.07
    • Product Weight (lb): 2
    • Recommended Forward Torque Range (ft-lb): 2.7-13
    • Recommended Forward Torque Range (in-lb): 32-159
    • Recommended Forward Torque Range (nm): 3.6-18
    • Retainer Type: Quick Change
    • Reversible: Reversible
    • Side to Center Distance (in): 1
    • Side to Center Distance (mm): 25
    • User Interface: No Display
    • Voltage DC: 20
    • Warranty: 1-year Tool, 2-year Battery, 3-year Charger
    • Wireless Tool Tracking: No Wireless Functionality
    • Wireless Tool Tracking: Mini USB
    SKU: IR QXFN2PT018PQ04
    Availability:
    Price: Call for pricing
    *
    *
    *
