Qx Wireless 40V 40Nm Multiplied 180 Nm

IR QXX5A45T0180PS12

3/4" 40V Cordless Angle Torque Wrench, 1593 in-lb, Bare Tool, Bluetooth/802.15.4

Description: Meet the tool that's taking torque to the next level - the QX Series 40V Cordless Torque Multiplier, packed with all the power and precision to perform like no wrench has before. A highly evolved 40V addition to the QX Series, QX Series 40V Cordless Torque Multiplier is more rugged, powerful, and twice as fast as its 20V QX Series counterpart while still offering premium accuracy, comfort, and control. An on-board persistent clock automatically timestamps, an advanced cooling fan extends runtime, and an ergonomic handle maximizes support. But next-gen torque demands next-gen tech, which is why the 40V seamlessly integrates with the INSIGHT Connect app and INSIGHTqcx Controller to easily log tightening data, program tool functions, and so much more. Unmatched speed, unbound accessibility, unmistakable data - only with the uncompromising QX Series 40V Cordless Torque Multiplier.

Features And Benefits:

• Closed-loop transducer delivers a torque accuracy of +/- 5%
• Enhanced quantitative feedback – displaying the actual measured torque or angle result
• Integrated gearbox provides premium quality and accuracy
• Brushless Motor offers maximum durability
• Intuitive qualitative feedback using Green, Red, and Yellow indicators
• 360° adjustable handle, with 6 mm threaded port for eye hooks or other tethering points, provides operator comfort, flexibility and safety options
• Standard or custom reaction arms available to match your application needs
• Optional wireless communication for process control with I/O and data collections (USB connection standard)
• 1,200 cycles of onboard tightening data storage
• Multiple Programming Methods: Wirelessly Through INSIGHTqcx Controller, Through USB with INSIGHTqcx Controller, Insight Connect Android App and ICS Software, Through On Board Tool Display/ Key
• Offer option for Insight Connect Android APP

• Includes: Bare tool only, batteries and charger sold separately.
• Actuation/Throttle Type/Switch Type: Trigger
• Anvil Length: Standard

• Built-in Light: No

• Color: Grey
• Configuration/Handle Type: Right Angle
• Data Storage Capacity: 1200 cycles
• Drive Size (in): 3/4
• Drive Type: Square
• Duty Rating: Heavy Duty

• Housing Material: Impact and chemical-resistant composite housing and patented steel reinforced frame

• Max Free Speed (rpm): 110
• Max Torque (ft-lb): 133
• Max Torque (in-lb): 1593
• Max Torque (nm): 180
• Motor: Brushless Motor

• Power Source: Battery Powered

• Reaction Bar: Yes
• Recommended Forward Torque Range (ft-lb): 12-133
• Recommended Forward Torque Range (in-lb): 142-1593
• Recommended Forward Torque Range (nm): 16-180
• Retainer Type: Thru-hole
• Reversible: Reversible

• Tether Style: Tether Included
• User Interface: No Display
• Voltage DC: 40
• Warranty: 1-year Tool, 2-year Battery, 3-year Charger
• Wireless Tool Tracking: Bluetooth
• Wireless Tool Tracking: 802.15.4

• Accessories: BC1161
• Accessories: BL4011

• Parts: NSP-299-CIR72
• Parts: NSP-299-M5X45

• Parts: NSP-766-W2222
• Parts: NSP-A48
• Parts: VP2-364
• Parts: VP2-377A
• Parts: VP2-400-T
• Parts: VP2-405
• Parts: VP2-405-2
• Parts: VP2-49
• Parts: <
